No specification added.
General
Brand
Tenda
Model
Tenda CH3-WCA
Usage
Outdoor
Type
IP Camera
Camera
Number of Camera
1
Camera Type
Pan & Tilt
Mega Pixels (MP)
3.0
Max. Camera Resolution
2304 x 1296
Secondary Camera Type
Not Applicable
Secondary Camera Mega Pixel (MP)
Not Applicable
Secondary Camera Max Resolution
Not Applicable
Sensor Type.
1/3 Inch Progressive Scan CMOS
Resolution
2304 x1296
Day & Night
ICR Type
Night Vision
Yes
Night Vision Mode
Color
Lens
Number of Lens
Single Lens (Primary)
Lens
4mm
Focal Length
4mm
PTZ
No
Viewing Angle.
Horizontal: 83.3 Degree, Vertical: 53.1 Degree, Diagonal: 91 Degree
Dual-Stream
Yes
Frame Rate
1-30fps, Default 20fps
Noise Reduction
Yes
Digital Noise Reduction (DNR)
3D DNR
Wide Dynamic Range (WDR)
DWDR
Network & Connectivity
Sim Supported
No
Sim Network Type
Not Applicable
Interface(s)
1 x RJ45 10M/100M auto-negotiation Ethernet port
Wi-Fi
Yes
Wi-Fi Details
IEEE 802.11b/g/n @2.4GHz
Security
Security
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Motion Detection
Yes
Human Detection
Yes
Dust Protection
Yes
Water Protection
Yes
Technical Info
Scanning System
Progressive
Video Type
H.265, H.264
Wavelength
850nm
Mic & Speaker
Both Mic and Speaker
Audio Communication
Two-Way Audio
Frequency
2.4GHz(DSSS/OFDM): 2412MHz-2472MHz(CH1-CH13)
Ingress Protection Grade
IP65
Working Distance
Unmentioned
Protocols
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP, WebSockets
Physical Description
Form-Factor
Dome
Smart Alarm
Motion Detection, Tempering Detection, Human Detection, Vehicle Detection
Card Slot
Yes
Storage Type
MicroSD
Storage Supported
Up to 512GB
Indicator LED
Yes
Button
Reset x 1
Body Material
Plastic
Color
Black & White
Dimensions
120 x 120 x 146mm
Weight (gm)
367 gm
Relevant Accessories (Not Included)
Outdoor Wi-Fi Camera,Power Adapter (cord length: 3m), Mounting Bracket, Mounting Accessories Kit, Waterproof Kit, Quick Installation Guide
Power
Power
DC 12V 1A
Battery Capacity
Not Applicable
Battery Backup
No
Battery Backup Time
Not Applicable
Operating Temperature
-30 Degree to 60 Degree C
Storing/Storage Temperature
-40 Degree to 70 Degree C
Operating Humidity
10%-95%RH (non-condensing)
Storing/Storage Humidity
3% ~ 95%RH (non-condensing)
Warranty
Warranty Details
1 Year (Without Adapter)
Additional Info
Others
Lens Aperture: F1.6, Supplementary Light: 2 IR Lights, 2 Spotlights, Supplementary Light Distance: Up to 30 m/100 ft (depending on environment), Night Vision Mode: Smart Mode, Full Color Mode, Black & White Mode, Main Stream Resolution: 2304 x 1296, 1920 x 1080, 1280 x 720, Sub Stream Resolution: 640 x 360, 352 x 288, Bit Rate: 512kbps -- 4096kbps, Bit Rate Control: CBR,VBR, Audio Encoding Format: G.711A, G.711U, AAC, Audio Sampling Rate: 8 kHz, Web Browser: Plug-in free live view: Chrome, Edge, Opera, Pan Movement Range: 0 Degree --355 Degree Tilt Movement Range: 0 Degree--90 Degree, Preset: 6, Patrol: Panoramic Patrol, Preset Patrol, Antenna: Internal antenna, Wireless Standard: IEEE 802.11 b/g/n/ax, Transmission Rate: Up to 287Mbps, Channel Width 20/40 MHz, Modulation: DSSS/OFDM/OFDMA, Transmit Power: 2.4GHz: <0.1W(EIRP), Smart Linkage: Sound&light Alert, Human Tracking, DIY Audio: 3 Customized Audios, ONVIF, Audio Input: Built-in MIC, adjustable microphone volume, Audio Output: Built-in Speaker, 79 dBA (Alarm sound at 1 meter), adjustable sound level, LED Indicator: Dual Color (red & blue), LED Indicator, Power 12 V DC, 1A, 5.5mm&2.1mm Power Plug, Smart Integration: Amazon Alexa, Installation Method: Wall Mounting, Ceiling Mounting, Pole Mounting. Certification: CE, RoHS, FCC, RCM, UKCA.
Specialty
Smart Full-Color Night Vision Professional Wi-Fi6 Transmission, Smart Full-Color, Deep Learning, Human/Vehicle Detection, Auto-patrol, Smart Tracking, Sound and Light Alarm, Diversified Storage, Equipped with F1.6 aperture lens, infrared lights and spotlights, designed to make protection last all night. two High-Power Spotlights and Infrared Lights. Empowered by an NPU module and a high-performance SOC boasting advanced deep-learning technology, the camera can accurately detect humans and vehicles, thus minimizing false alarms. With the latest Wi-Fi6 technology, built-in special antenna for signal enhancement,it offers better anti-interference performance and lower latency compared to Wi-Fi4, allowing your security range wider. 360 Degree Panoramic Coverage Omnidirectional Protection. When people enter the protected area, the camera will automatically tracking and giving anaudible warning with spotlight flashing (three audio alarms can be customized), after tracking is completed, the camera will return to the position you need to guard. Sharing Camera to Your Family to Protect Safety Jointly.
Country Of Origin
China
Made in/ Assemble
China
